Precision Frames Parts CNC Machining for Robotics Industry
Precision frames provide the base for the structural platforms and serve as a surface for the robotic systems. At Zintilon, we provide the CNC perfectly machined components of the precision frames. The advanced multi-axis machining provide optimal flatness, stability, dimensional stability, and accuracy of the machining frames and components for the sequential automation of the industrial robots for reliable performance and repeatable positioning.We specialize in the combination of machining and robotic automation systems for the complex frames and the integration of advanced robotic systems for complex automation systems in the industrial robotics systems.
- Machining for complex frame geometries and mounting surfaces
- Tight tolerances up to ±0.005 in
- Precision milling, drilling & flatness grinding
- Support for rapid prototyping and full-scale production
- ISO 9001-certified robotics manufacturing
Trusted by 15,000+ businesses
Why Robotics Companies
Choose Zintilon
Increased Productivity
Engineers get time back by not dealing with immature supply chains or lack of supply chain staffing in their company and get parts fast.
10x Tighter Tolerances
Zintilon can machine parts with tolerances as tight as+/ - 0.0001 in -10x greater precision compared to other leading services.
World Class Quality
Zintilon provides medical parts for leading aerospace enterprises, verified to be compliant with ISO9001 quality standard by a certified registrar.
From Prototyping to Mass Production
Zintilon provides CNC machining for precision frame components and related structural platforms for industrial automation, collaborative robots, and research robotics projects
Prototype Precision Frames
Before full-scale production, we provide high-precision prototypes of precision frame components to test mounting alignment, check structural rigidity, and ensure proper assembly.
Key Point
Key Point
- Tight tolerances (±0.005 in)
- Rapid prototyping with high precision
- Early detection of design, material, and structural integrity
EVT – Engineering Validation Test
Quickly iterate on the frame prototypes in the design to ensure the structural and alignment objectives are met. This provides the capability to detect potential issues for a smoother transition to full-scale robotics manufacturing.
Key Point
Key Point
- Confirm functional efficiency of prototypes
- Conduct rapid design revisions
- Confirm readiness pre-production
DVT – Design Validation Test
Meticulously design, capture, and validate frames of different materials for dimensional accuracy, structural performance loading for design efficiency, then design rotational symmetry, and prepare for mass production.
Key Point
Key Point
- Confirm design integrity and flatness
- Test for multiple materials and configurations
- Confirm performance for production readiness
PVT – Production Validation Test
Examine and validate mass production capability for Frames of Precision and preempt prototype production constraints to control cost, and optimize project time, and ensure consistent production and efficiency.
Key Point
Key Point
- Examine mass production capabilities
- Identify and preempt production challenges
- Confirm part quality consistency
Mass Production
Deliver frames of high precision and grade. Meet production deadlines to assure structural performance for robot manufacturers and integrators of automation with precise mass production.
Key Point
Key Point
- Reliable, high-volume production
- Precision industrial-grade quality
- Rapid production with tight quality limits
Simplified Sourcing for
Robotics Industry
Our robotics industry parts manufacturing capabilities have been verified by many listed companies. We provide a variety of manufacturing processes and surface treatments for robotics parts including titanium alloys and aluminum alloys.
Explore Robotics Components
Discover our full range of precision CNC machined robotics components, designed for strength, stability, and seamless motion. Explore parts for robotic arms, joints, actuators, frames, and end effectors, all crafted to ensure high accuracy, repeatability, and performance in modern automation and robotics systems.
- Base Plates
- Custom Arm
- High-Accuracy Joints
- Precision Gears
- Custom Gearbox
- Precision Bearings
- Custom Bearing Housings
- Precision Shafts
- Custom Spindles
- Precision Sensors
- Custom Sensor Housings
- Precision End Effectors
- Custom Grippers
- Custom Structural
- Precision Brackets
- Custom Mounts
- Precision Wheels
- Custom Tracks
- Precision Gear Racks
- Custom Linear
- Precision Actuators
- Custom Valve
- Precision Housings
- Custom Cover
Robotics Precision Frames Machining Capabilities
The Integrated Precision Machining for Robotics Industry, with high grade CNC centers, surface grinding machines, and advanced cutters for precision work tables facilitates the design and construction gantry and robot frames for the advanced control systems. Design and construction ensure the control frames maintain rigid construction, with planes of defined lecturing surfaces, and primary reference surfaces for positional accuracy and design stability.
We utilize laser interferometry and CMM verification to assess and adjust flatness, and we also offer precision CNC milling, coordinated drilling, surface grinding, and stress-relieving operations, providing custom mounting surfaces and reinforcing structural integrity. Machined precision frames are manufactured with aluminum tooling plates (ATP-5, MIC-6), steel plates (A36, 1018), cast iron (Class 40), and granite composite, which guarantee high performance under dynamic industrial loads at sensitive environments due to their structural dimensional stability and vibration damping properties.
We utilize laser interferometry and CMM verification to assess and adjust flatness, and we also offer precision CNC milling, coordinated drilling, surface grinding, and stress-relieving operations, providing custom mounting surfaces and reinforcing structural integrity. Machined precision frames are manufactured with aluminum tooling plates (ATP-5, MIC-6), steel plates (A36, 1018), cast iron (Class 40), and granite composite, which guarantee high performance under dynamic industrial loads at sensitive environments due to their structural dimensional stability and vibration damping properties.
Aerospace
Materials & Finishes
Materials
We provide a wide range of materials, including metals, plastics, and composites.
Finishes
We offer superior surface finishes that enhance part durability and aesthetics for applications requiring smooth or textured surfaces.
Specialist Industries
you are welcome to emphasize it in the drawings or communicate with the sales.
Materials for Precision Frames Components
For Precision Frames Machining for Robotics Industry, our CNC machine shop offers more than 30 industrial-grade structural materials and precision alloys, which allows us to enhance customization for platform manufacturing and rapid prototyping while meeting target industrial grades and standards for precision.
High machinability and ductility. Aluminum alloys have good strength-to-weight ratio, high thermal and electrical conductivity, low density and natural corrosion resistance.
Price
$ $ $
Lead Time
< 7 days
Tolerances
Down to ±0.003 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Stainless steel alloys have high strength, ductility, wear and corrosion resistance. They can be easily welded, machined and polished. The hardness and the cost of stainless steel is higher than that of aluminum alloy.
Price
$ $ $
Lead Time
< 7 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Titanium is an advanced material with excellent corrosion resistance, biocompatibility, and strength-to-weight characteristics. This unique range of properties makes it an ideal choice for many of the engineering challenges faced by the medical, energy, chemical processing, and aerospace industries.
Price
$$$
Lead Time
< 10 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Steel is a strong, versatile, and durable alloy of iron and carbon. Steel is strong and durable. High tensile strength, corrosion resistance heat and fire resistance, easily molded and formed. Its applications range from construction materials and structural components to automotive and aerospace components.
Price
$ $ $ $ $
Lead Time
< 10 days
Tolerances
Down to ±0.001 mm (routing)
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Highly resistant to seawater corrosion. The material’s mechanical properties are inferior to many other machinable metals, making it best for low-stress components produced by CNC machining.
Price
$ $ $ $ $
Lead Time
< 10 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Few metals have the electric conductivity that copper has when it comes to CNC milling materials. The material’s high corrosion resistance aids in preventing rust, and its thermal conductivity features facilitate CNC machining shaping.
Price
$$$
Lead Time
< 10 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Brass is mechanically stronger and lower-friction metal properties make CNC machining brass ideal for mechanical applications that also require corrosion resistance such as those encountered in the marine industry.
Price
$$$
Lead Time
< 10 days
Tolerances
Down to ±0.005mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Zinc is a slightly brittle metal at room temperature and has a shiny-greyish appearance when oxidation is removed.
Price
$ $ $ $ $
Lead Time
< 10 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Iron is an indispensable metal in the industrial sector. Iron is alloyed with a small amount of carbon – steel, which is not easily demagnetized after magnetization and is an excellent hard magnetic material, as well as an important industrial material, and is also used as the main raw material for artificial magnetism.
Price
$ $ $ $ $
Lead Time
< 10 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Due to the low mechanical strength of pure magnesium, magnesium alloys are mainly used. Magnesium alloy has low density but high strength and good rigidity. Good toughness and strong shock absorption. Low heat capacity, fast solidification speed, and good die-casting performance.
Price
$ $ $ $
Lead Time
< 7 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Let’s Build Something Great, Together
FAQs: Precision Frames for Robotics Applications
Precision robotic frames are engineered structural platforms that provide mounting surfaces and positional reference for integrating various robots. These frames include robot base frames which anchor industrial robots and offer precise leveling surfaces that are bolted to the floor. Other examples include gantry frames that provide support for linear motion systems over work areas, worktable frames that offer flat reference surfaces for part fixturing, multi-station frames that index multiple work zones, modular frames that use T-slot extrusions for reconfigurable cells, granite frames which provide the most thermal stability for metrology applications, and meld frames that combine machined surfaces with fabricated structures to weld to swarm and provide support to large-scale systems.
Aluminum tooling plates, including ATP-5 and MIC-6, offer pre-stressed dimensional stability and guaranteed flatness, lightweight construction which reduces the requirements for the foundation, excellent machinability for integrated features, and thermal conductivity for equality at temperatures. Cast iron offers excellent dimensional stability with minimal thermal expansion, proven performance in precision machinery, and cast iron offers superior vibration dampening which reduces dynamic deflection by 40 percent. Steel provides ample strength for heavy-load applications that support multi-ton payloads, cost-effectiveness for ampliative structures, and weldability for large fabricated structures. Granite composites offer exceptional flatness retention over decades, near-zero thermal expansion, and non-magnetic properties.
CNC processes that are used for precision frames include Face milling which creates flat mounting surfaces achieving flatness to within 0.005 inches which are large area frames. Schematic coordinate drilling produces mounting hole patterns and hole positioning with an accuracy of ±0.003 inches with respect to the robot bolt circles. Boring machines perform the precision boring of large diameter features for rotary tables for large diameter rotary tables and bears. Tapping produces the threaded mounting holes for the attachments of the equipment. T-slot milling generates the modular mounting channels. Surface grinding not only produces flatness but achieves that flatness to below 0.001 inches specifically on the critical datum surfaces. Cross section heat treatment for stress relieving and continuous machining provides the needed flatness and precision of the frame without the unwanted warping.
The flatness of the surfaces achieves tolerances of ±0.005 inches which spans large areas of 2 meters. The mounting holes are positioned with an accuracy of ±0.003 inches for equipment alignment. The alignment of mounting surfaces achieves 0.005 inches in perpendicularity and 0.010 inches in parallelism for opposing surfaces or faces. The overall dimensions are ±0.020 inches which ensures reliable equipment mounting. The accuracy of positioning drastically improved to 0.1 millimeter which is stable for the equipment during thermal cycling in the range of 15 to 35 degrees Celsius.
Yes. We offer flexible manufacturing capabilities including:
Rapid prototyping for design validation
Low-volume production for specialized applications
High-volume production with consistent quality control
Full structural and dimensional verification at every stage
Rapid prototyping for design validation
Low-volume production for specialized applications
High-volume production with consistent quality control
Full structural and dimensional verification at every stage
Each component manufactured undergoes traceability along the ISO 9001 quality management systems and is checked against the design requirements for dimensional accuracy, flatness, perpendicularity, and traceability. Documentation accompanies structural platforms in industrial robotics where we have stable mounting robotic platforms with a repeatable position of 0.05 millimeters and stable long-term free dimensional control over temperature, dynamic loading, and structural de-stabilization.
We provide comprehensive finishing solutions tailored to aerospace requirements:
Anodizing (Type II and Type III)
Passivation for corrosion resistance
Precision polishing for aerodynamic surfaces
Custom protective coatings and thermal barriers
Anodizing (Type II and Type III)
Passivation for corrosion resistance
Precision polishing for aerodynamic surfaces
Custom protective coatings and thermal barriers
Standard robot base plates and worktables require a lead time of 10–15 business days and large multi-level gantry frames with integrated features take 4–6 weeks, which includes machining, stress relief, and precision grinding of the frames. For rapid cell design validation and robot mounting verification, prototype frames are completed in 7–10 days.
Indeed, we tailor lightweight frames for mobile robots, reducing platform mass, designing modular frames with standardized interfaces for quick reconfiguration in flexible manufacturing, developing vibration-isolated frames for precision assembly operations, working thermally stable frames for measurements that require maintaining flatness within 10 microns across a 20°C range, and integrated frames with mounted surfaces that combine cable management, pneumatics distribution, and safety barriers.
Frames with flat mounting surfaces within ±0.005 inches guarantee that equipment contact is uniformly distributed, preventing rocking and twisting which compromises calibration and repeatability of the robot. Accurate hole patterns within ±0.003 inches guarantee proper robot mounting and maintained designed tool center point (TCP) position within 0.1 mm. All perpendicular surfaces guarantee that mounts square, preventing kinematic errors. All strategic ribbing and reinforcement promote ridding preventing deflection under payload and dynamic forces. Stress relieved while maintaining surfaces promoted stability dimensional through thermal cycling and vibration, properly prepared surfaces for automation. Repeatability, positioning within ±0.05 mm was achieved through precise automation, stable calibration of the robot was maintained over extended periods.
