Prosthetic Components CNC Machining for Medical Industry
Prosthetic components are precision- engineered tools that provide mobility and functionality to those who have lost or altered limbs. Zintilon CNC prosthetic components machining covers the use of sophisticated multi-axis machining to precision lightweight and durable engineered components and to robustly functionality to engineered parts for their performance for daily living and rehabilitative therapy.
- Machining for complex prosthetic geometries and joint mechanisms
- Tight tolerances up to ±0.002 in
- Precision milling, turning & lightweight optimization
- Support for rapid prototyping and full-scale production
- ISO 13485-certified medical device manufacturing
Trusted by 15,000+ businesses
Why Medical Companies
Choose Zintilon
Fast Delivery
A professional engineering team that can respond quickly to customer needs and provide one-stop services from design to production in a short period of time to ensure fast delivery.
High Precision
We are equipped with automated equipment and sophisticated measuring tools to achieve high accuracy and consistency, ensuring that every part meets the most stringent quality standards.
ISO13485 Certified
As a ISO13485 certified precision manufacturer, our products and services have met the most stringent quality standards in the automotive industry.
From Prototyping to Mass Production
Worlwide Zintilon.Interface CNC Machining for Prosthetic Components and Orthotic Devices. Distributed to Rehabilitation Centers, Prosthetic Centers, and Medical Device Manufactures.
Prototype Prosthetic Components
CNC Machined Prototypes of Prosthetic Components Provide the Precision Measured to Replicate the Final Designed Prosthetic Element. Evaluate the Prosthetic in Mechanical Function to Asses Weight Distribution and check Alignment Prior to the Medical Prosthetics Production Scale.
Key Points:
Key Points:
- Rapid prototyping with high precision
- Tight tolerances (±0.0002 in)
- Test design, biomechanics, and patient comfort early
EVT – Engineering Validation Test
Prototyping during the EVT stage of the design using durable and functional materials for the design. Identifying and addressing design issues during prototyping which facilitates the transition to volume production of the medical device.
Key Points:
Key Points:
- Validate prototype functionality
- Rapid design iterations
- Ensure readiness for production
DVT – Design Validation Test
Systematically assess the dimensional and mechanical properties of diverse biomaterials to refine the functional performance of prosthetic components before large-scale production.
Key Points:
Key Points:
- Confirm design integrity and strength
- Test multiple materials and configurations
- Ensure production-ready performance
PVT – Production Validation Test
Assess the large-scale production of prosthetic components to reveal production-related obstacles, ensuring the reliability and efficiency of the manufacturing process before it fully commences.
Key Points:
Key Points:
- Test large-scale production capability
- Detect and fix process issues early
- Ensure consistent part quality
Mass Production
Deliver medical-grade prosthetic components to rehabilitation centers and prosthetic facilities with on-time delivery. Ensure reliable performance in mobility and prosthetics to facilitate the rehabilitation process.
Key Points:
Key Points:
- Consistent, high-volume production
- Precision machining for medical-grade quality
- Fast turnaround with strict quality control
Simplified Sourcing for
the Medical Industry
Our precision manufacturing capabilities are widely used in the medical industry. CNC machining, sheet metal fabrication and other technologies ensure high precision and heat resistance in the application of medical grade materials such as titanium alloy and PEEK.
Explore Other Medical Components
Browse our extensive selection of CNC machined medical parts, engineered to meet the highest quality and hygiene standards. From implant-grade components and instrument handles to housings for imaging systems and lab automation equipment, we deliver precision solutions for the evolving needs of the medical industry.
- Surgical Instruments
- Orthopedic Implants
- Bone Screws
- Bone Plates
- Hip Implants
- Knee Implants
- Dental Implants
- Medical Housings
- Surgical Handles
- Medical Shafts
- Surgical Forceps
- Scalpel Components
- Medical Couplings
- Medical Fittings
- Endoscopic Components
- Medical Valves
- Catheter Components
- Medical Connectors
- Surgical Clamps
- Medical Hubs
- Surgical Pins
- Surgical Drills
- Medical Brackets
- Medical Casings
- Medical Tubing
- Medical Adapters
- Medical Covers
- Implantable Components
- Medical Device Enclosures
Medical Prosthetic Components Machining Capabilities
Prosthetic Components CNC Machining for Medical Industry is complemented by our CNC machining centers, lightweight optimization software, and skilled medical device machinists. Every component, from prosthetic knee joints to ankle mechanisms and socket adapters with critical alignment features, is prepared with optimum strength-to-weight ratio, mechanical reliability for the device, and patient mobility in mind.
For the biomechanical function and the endurance of the part, we also incorporate load testing and gait analysis. prosthetic components are machined from titanium alloys (Ti-6Al-4V) and aluminum alloys (7075-T6, 6061-T6) and stainless steel (316L, 17-4 PH) and carbon fiber composites, balanced for strength and corrosion resistance to withstand daily and environmental exposure.
For the biomechanical function and the endurance of the part, we also incorporate load testing and gait analysis. prosthetic components are machined from titanium alloys (Ti-6Al-4V) and aluminum alloys (7075-T6, 6061-T6) and stainless steel (316L, 17-4 PH) and carbon fiber composites, balanced for strength and corrosion resistance to withstand daily and environmental exposure.
Aerospace
Materials & Finishes
Materials
We provide a wide range of materials, including metals, plastics, and composites.
Finishes
We offer superior surface finishes that enhance part durability and aesthetics for applications requiring smooth or textured surfaces.
Specialist Industries
you are welcome to emphasize it in the drawings or communicate with the sales.
Materials for Prosthetic Components
For Prosthetic Components Machining for the Medical Industry, our CNC machine shop has an extensive selection of materials. With over 20 medical-grade alloys, composites, lightweight alloys, and FDA-compliant materials for reliable quality, we are positioned to assist on rapid prototyping and custom prosthetic manufacturing.
High machinability and ductility. Aluminum alloys have good strength-to-weight ratio, high thermal and electrical conductivity, low density and natural corrosion resistance.
Price
$ $ $
Lead Time
< 7 days
Tolerances
Down to ±0.003 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Stainless steel alloys have high strength, ductility, wear and corrosion resistance. They can be easily welded, machined and polished. The hardness and the cost of stainless steel is higher than that of aluminum alloy.
Price
$ $ $
Lead Time
< 7 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Steel is a strong, versatile, and durable alloy of iron and carbon. Steel is strong and durable. High tensile strength, corrosion resistance heat and fire resistance, easily molded and formed. Its applications range from construction materials and structural components to automotive and aerospace components.
Price
$ $ $ $ $
Lead Time
< 10 days
Tolerances
Down to ±0.001 mm (routing)
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Titanium is an advanced material with excellent corrosion resistance, biocompatibility, and strength-to-weight characteristics. This unique range of properties makes it an ideal choice for many of the engineering challenges faced by the medical, energy, chemical processing, and aerospace industries.
Price
$$$
Lead Time
< 10 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Highly resistant to seawater corrosion. The material’s mechanical properties are inferior to many other machinable metals, making it best for low-stress components produced by CNC machining.
Price
$ $ $ $ $
Lead Time
< 10 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Brass is mechanically stronger and lower-friction metal properties make CNC machining brass ideal for mechanical applications that also require corrosion resistance such as those encountered in the marine industry.
Price
$$$
Lead Time
< 10 days
Tolerances
Down to ±0.005mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Few metals have the electric conductivity that copper has when it comes to CNC milling materials. The material’s high corrosion resistance aids in preventing rust, and its thermal conductivity features facilitate CNC machining shaping.
Price
$$$
Lead Time
< 10 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Zinc is a slightly brittle metal at room temperature and has a shiny-greyish appearance when oxidation is removed.
Price
$ $ $ $ $
Lead Time
< 10 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Iron is an indispensable metal in the industrial sector. Iron is alloyed with a small amount of carbon – steel, which is not easily demagnetized after magnetization and is an excellent hard magnetic material, as well as an important industrial material, and is also used as the main raw material for artificial magnetism.
Price
$ $ $ $ $
Lead Time
< 10 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Due to the low mechanical strength of pure magnesium, magnesium alloys are mainly used. Magnesium alloy has low density but high strength and good rigidity. Good toughness and strong shock absorption. Low heat capacity, fast solidification speed, and good die-casting performance.
Price
$ $ $ $
Lead Time
< 7 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Let’s Build Something Great, Together
FAQs: Prosthetic Components for Medical Applications
Prosthetic components are precisely engineered mechanical devices which provide ambulation for people with limb loss, specifically transtibial (below-knee), transfemoral (above-knee), transradial (below-elbow), and transhumeral (above-elbow) amputations. Prosthetic knee joints can range from being mechanical, microprocessor controlled, to more advanced configurations. Other components include ankle-foot mechanisms which provide dorsiflexion and plantarflexion control, pyramid adapters which align and adjust prosthetic limbs, socket adapters which connect prosthetic limbs to patient sockets, pylon tubes which provide structural support, shock absorption, and stabilization, and foot components which incorporate dynamic response, multi-axial designs, and more. Other adjunct components include joint rotation adapters, elbow joints, wrist rotators, and terminal devices related to upper limb prosthetics, which are all integrated into prosthetic limbs.
Titanium Ti-6Al-4V provides exceptional strength-to-weight ratio enabling lightweight prosthetics reducing energy expenditure by 20 to 30 percent during ambulation, excellent biocompatibility for skin contact, corrosion resistance to perspiration and environmental exposure, and fatigue strength supporting millions of gait cycles. Aluminum 7075-T6 and 6061-T6 deliver lightweight construction with adequate strength for prosthetic frames and adapters, cost-effectiveness, excellent machinability for complex geometries, and corrosion resistance with anodized finishes. Stainless steel provides maximum strength for high-stress components including knee joint pins and fasteners, wear resistance at articulating surfaces, and proven durability. Carbon fiber composites offer ultimate weight reduction with strength comparable to aluminum at 40 percent of the weight, energy storage and return for dynamic prosthetic feet, and design flexibility for patient-specific applications.
Complex three-dimensional shapes are produced in the CNC milling of knee joint housings, ankle mechanisms, and socket adapters with built-in alignment features. CNC turning creates cylindrical pylon tubes, joint pins, and rotation adapters. Concentricity of the parts is achieved within 0.002 inches. Coordinate drilling creates mounting hole patterns with position accuracy of ±0.005 inches. Topology optimization with FEA software. 30 to 50 percent of structural material is retained while weight is significantly reduced. Cold composite machining and diamond tooling prep the carbon fiber components. Anodizing adds a lustrous finish to aluminum while it provides protection against corrosion.
Mounting hole position tolerances of ±0.002 enable alignment and interchangeability of components, bearing bore tolerances of ±0.001 facilitate smooth articulation of the joint, and ±0.002 concentricity which is required to achieve rotation of parts. Flatness of 0.005 inches is controlled on mounting surfaces and overall dimensions are controlled to ±0.010 inches for compatibility of components. Critical interface dimensions ensure a socket standardized to the prosthesis and a patient socket, it is controlled within ±0.003.
Yes, we provide rapid prototyping to verify fit and test assembly, with same-day CAD-to-part capability available for critical projects. For custom automation cells and research platforms, we perform low-volume production of 20 to 500 brackets. For standardized robot models, we perform high-volume production of thousands to tens of thousands of brackets annually, incorporating complete dimensional inspection, flatness verification, and material certifications.
All components are manufactured under ISO 13485 certified quality management systems for medical devices, ensuring full compliance with FDA regulations for Class I and Class II prosthetic devices, European Medical Device Regulation (MDR) requirements, ISO 10328 structural testing for lower limb prosthetics including static and cyclic loading, complete traceability from raw material through final product, and adherence to Good Manufacturing Practices ensuring patient safety, mobility, and quality of life for individuals with limb loss.
We provide comprehensive finishing solutions tailored to aerospace requirements:
Anodizing (Type II and Type III)
Passivation for corrosion resistance
Precision polishing for aerodynamic surfaces
Custom protective coatings and thermal barriers
Anodizing (Type II and Type III)
Passivation for corrosion resistance
Precision polishing for aerodynamic surfaces
Custom protective coatings and thermal barriers
Standard prosthetic adapters and pylon components take 8-14 business days while custom patient specific joints and mechanisms take 3 to 5 weeks and include design optimization, machining, and surface treatment. In 7 to 10 days we can complete patient fitting trial components which streamlines the process for prosthetic fabrication and delivery.
Absolutely. We create specialized components that enhance energy return and impact absorption to accommodate running and sporting activities. For swimming and other water sports, we use corrosion-resistant and sealed materials to fabricate water-resistant components. For pediatric users, we incorporate adjustable growth features. For elderly users, we design lightweight components that minimize energy expenditure. We create heavy-duty components for occupational use that support loads over 150 kilograms. Advanced prosthetics include microprocessor-controlled joint housings. We also design custom geometries for bilateral amputees, hip disarticulation, and congenital limb differences
Correctly mounted interfaces within ±0.002 inches guarantee alignment and preservation of the correct position of the prosthetic. Thus, compensatory gait patterns are avoided and energy expenditure is reduced. The joint surfaces articulated with friction coefficients of <0.1 which allowed the prosthetic limb to mimic the movement of a natural joint. The prosthetic limb’s weight was reduced by 30 to 50 percent, as strategic material removal lightweight optimization was applied. This reduced the metabolic cost of walking by 15 to 25 percent. Optimized geometry prevented under designed stress concentration of stressful regions leading to prolonged component life of over 3 million gait cycles (5 years of normal use). The load bearing components were designed to support 5 times body weight during running and jumping, thus, the materials provided were adequate and of good quality. The durable, corrosion-resistant finish that withstands damage from perspiration, water, and the environment was impressive. Excellent modular design and quality manufacturing allowed components to be interchanged and alignment adjusted, improving the fit and function of the prosthetic limb, thus, improving the quality of life of limb loss gaiters.
