Aluminum 7075-T6 is the strongest commercially available aluminum with a tensile strength of 572 MPa, which makes it a perfect support link because it can support loads between 50-300 kN and can withstand repeated loads 100,000 times (with an S-N curve supporting it). This aluminum is perfect because it keeps a low weight and is lightweight at a specific strength of 205 kN·m/kg. It can produce linkages with lengths of 300-2,000 mm and can be more efficient by allowing the actuation system to be less powerful (requiring 20-30% less power). It is highly machinable with a dimensional accuracy of ±0.030mm for I-beams or tubular sections with optimized design. They also have the required accreditation for the aerospace industry for high lift commercial systems. Titanium offers the best strength to weight ratio for pivot fittings at a specific strength of 300 kN·m/kg, especially since these systems can support high concentrations of load at 50-300 kN. It can also withstand tensile strengths of up to 900 MPa. It also has excellent fatigue resistance, similar to 7075-T6, in that it can maintain structure and support over 100,000 cycles. Ti6Al4V also performs well in the marine and hydraulic system environments with only corrosion to preserve itself. The 7075-T6 aluminum and Ti6Al4V can withstand a galvanic corrosion reaction so it is safe to couple these two with each other.
4340 alloy steel clevis joints withstand bearing load with pin-in-hole configurations due to their remarkable tensile strength (1,520 MPa at 280-320 HBN). Because of their superior bearing strength (1,100+ MPa), compact clevis geomistries with minimal material are possible. With proper heat treatment, surface finish, and excellent fatigue resistance these joints can withstand 100,000+ load cycles. These joints are also highly machinable with an accuracy of ±0.025 mm in pinhole position and ±0.013 mm in diameter. 4340 alloy steel clevis joints also have an established aerospace pedigree in landing-gear and high-lift linkages.

CNC Milling obtains support link bodies and I-beam webs with dimensional tolerances of ±0.030mm and thickness I-beam webs of ±0.025mm. 5-axis machining pivots with complex fittings on the lower planes of the workpiece, and active geometry with dimensional tolerances of ±0.025mm. Boring, precision bearing cores with bores on the Ra (0.4 to 0.8 oil μm). It ensures that the proper fit of the bearings is spherical. Precision reaming provides interference and transition fits to the required ±0.012mm tolerance spherical of the bearings. Drilling with precision of the pivot pin holes with diameter tolerances of ±0.025mm and 0.013mm. Over 25mm to less than 40. Zero. EDM (Electrical Discharge Machining). E/C fusion of the workpiece with 2 complex clevis profiles. Also on legitimacy cutouts to within 0.020mm tolerance. Honing precision finishes the major dimensions of the bearing bore to within tolerances of ±0.008mm and with a surface finish of Ra 0.2 to 0.4 μm.
There’s a particular order that gets followed when heat treating. It starts with solution heat treatment and then moves to aging with aluminum (T6 and T7 tempers). After that there’s quenching and tempering with 4340 steel (28-35 HRC, or 280-320 HBN), and ends with 15-5 PH (H1025). 15-5 PH gets precipitation hardened to achieve HRC 42-46). Some examples of surface treatment are hard anodizing per MIL-A-8625 Type III (50-75 μm), chromate conversion per MIL-DTL-5541, and cadmium plating per AMS 2400 to protect steel (currently being phased) to protect against corrosion, along with electroless nickel plating per AMS 2404, a cadmium substitute. Other examples of surface treatment are passivation per ASTM A967, shot peening per AMS 2430, and dry film lubricant per MIL-PRF-46010 for bearing surfaces. These help with fatigue enhancement.

For the supports to function correctly, we hold a bore tolerance of the pivot bearings to ±0.015mm, with the required surface finish of Ra 0.4-0.8μm to ensure a proper slide fit while maintaining a diametral clearance of 0.025-0.075mm required for the articulation of the sphere bearing through a range of ±30 degrees when supporting loads of 50-300 kN. The supporting links have a dimensional tolerance of ±0.030mm over lengths of 300-2,000mm, with the web of the I-beam having a thickness tolerance of ±0.025mm to ensure the buckling of the compression structure does not occur due to a loss of support. The pivot pin holes have a positional tolerance of ±0.025mm with a diameter tolerance of ±0.013mm to ensure the synchronization of the flap motion is maintained to within ±1 degree left/right of the pivoting surface. The bore tolerances of the spherical bearing house are ±0.012mm to meet the proper fit, whether that being interference or transition, required by the bearings. A straightness tolerance of 0.40mm/m over the lengths of the links is required so that binding can be avoided. The bearing bore perpendicularity ±0.025mm to the attachment interface planes ensures that no edge loading can occur, while a clevis gap of ±0.15mm tolerance ensures proper pin clearance. The surface finishes meet the application required, with bearing surfaces requiring Ra 0.4-0.8μm, and structural surfaces Ra 1.6-3.2μm, with a standard concentricity of 0.025mm for the diameters being featured by the bearings.
These tolerances accompany maximum load factors 3.75-6.0g per FAR 25.697, 1.5 load factor safety, combined bending/tension/compression loads 50-300 kN, ±1 degree flap synchronization, articulation smoothness with binding forces <100N during travel, fatigue life exceeding 100,000 extension/retraction cycles with spectrum loading per ASTM E647, MIL-STD-1530D, AS9100D aerospace quality management, NADCAP special processes (heat treat per AMS 2759, NDT, chemical processing), FAA FAR 25.697 lift and drag devices, EASA CS-25, and MIL-A-8866.

Sure, we specialize is rapid prototyping CMM inspection where we check principal dimensions and GD&T seamlessly including position, perpendicularity, concentricity, and profile tolerances, and bearing bore where we use accurate measurement bore gauges, air gauging, and coordinate measuring machines to inspect with ±0.001mm resolution, verifying ±0.015mm tolerance with an astonishing finish of Ra 0.4-0.8μm. For pinholes, we employ gauges and optical comparators where we check an impressive ±0.002mm resolution which verifies ±0.025mm positional accuracy and ±0.013mm diameter tolerance. For straightness measurement, we laser alignment systems to verify 0.40mm/m linear meters across 300-2,000mm link lengths which is a remarkable outcome. As for material confirms using optical emission spectroscopy (OES), and X-ray fluorescence (XRF) which validates alloy composition per AMS specifications (7075, Ti-6Al-4V, 4340, 15-5PH). We also conduct extensive non-destructive testing (NDT) with particle inspection (MPI) per ASTM E1444/AMS 3041 for iron detecting surface and subsurface defects of 0.1-2mm depth, fluorescent penetrant inspection (FPI) per AMS 2644 for aluminum and titanium so we do not miss surface discontinuity inclusions of 0.05-1mm, and even perform ultrasonic inspection to assess internal void defects and porosity with eddy current testing for bearing surfaces and heat-affected surfaces. Rest assured, we also perform structural testing to ultimate loads a range of about 3.75-6.0g simulating 50-300 kN combined loads, with strain gauge monitoring and hydraulic actuator simulation. We even fatigue test forks simulating over 100,000 extension/retraction cycles with spectrum loading per ASTM E466/E647 and MIL-STD-1530D generating S-N.
The report explains that starting with data collection, data that shows the curves and the fatigue crack growth, specifically regarding the kinematic tests measuring the flap synchronization accuracy ($\pm$1$^{\circ}$) and the articulation binding forces over an angular range of 30$^{\circ}$. Orientation of the bearing, data that shows wear patterns over an extended number of cycles, and contact pressure and friction are characteristics of bearing interface testing that should be analyzed. Regarding finite element analysis (FEA), the values of stress, deflection, buckling, and overall structure will be theoretically analyzed, and the values should be within 10\% of the values collected in the experimental data. Validation of the heat treatment should be completed first, with documentation that fulfills the requirements of ASTM E18 (HRC 28-35 for steel, HRC 42-46 for 15-5PH) microstructure analysis and the stabilization of parameters that might change in training, should be examined and documented. Validation of surface treatment will include anodization as per MIL-A-8625 (thickness 50-75 encouraged) or specific citations, as well as plating thickness, and documentation of certification of FAR 21 and EASA Part 21G.
As far as supporting business jets, regional jets, military transport, and their upgrades, we provide low volume production (20-500 sets annually) as well as high volume production (in the thousands) for commercial transport jets. We can provide complete traceability of materials including certificates for metals and alloys used (7075, Ti-6Al-4V, 4340, 15-5PH) along with certificates for their heat treatments including certificates for time, temperature profiles and the hardness verification of necessary alloys. We can provide first article inspections (FAIR) according to aerospace standard 9102 along with complete volume measurements, geometric dimensional tolerancing (GD&T). We can also provide the documents required for the testing of materials of the metals, alloys, and structures to validate complete traceability for tensile, yield, and fracture strengths per standards (E8, E399) of the alloys used. We can provide the aerospace standards for non-destructive tests and traceable structural analysis of the metals to validate the ultimate load and fatigue performance were tested. We also validate the high performance of the microstructures to inhibit crack growth. Kinematic performance of the flap controls can also be documented. Finally, we can validate compliance with the aerospace standards for military and commercial jets.
