Precision Coffee Grinder Components CNC Machining for Consumer Goods Industry.
Precision coffee grinder parts are added to home and commercial equipment, such as coffee grinders. These parts allow the equipment to deliver a consistent coffee grind and optimal particle distribution as well as efficient performance. These parts include the grinding chamber, conical burrs, adjustment mechanisms, and motor couplings. At Zintilon, we focus on the machining of flat and conical burrs, grind adjustment rings, and dosing housing as well as bean hoppers, and we do our best to ensure extreme accuracy while paying attention to food-grade regulations and wear standards for the consumer coffee grinder and coffee beverage equipment.
- Ultra-precision burr machining with ±0.008mm tolerance for consistent grind size
- Food-safe materials: stainless steel 304/420, hardened tool steel, FDA-compliant plastics
- Burr hardness HRC 58-62 for extended sharpness and 500+ kg grinding capacity
- Surface finish Ra 0.4-0.8μm for optimal particle flow and easy cleaning
- ISO 9001-certified manufacturing with consumer goods industry expertise.
Trusted by 15,000+ businesses
Why Consumer Goods Companies
Choose Zintilon
Increased Productivity
Engineers get time back by not dealing with immature supply chains or lack of supply chain staffing in their company and get parts fast.
10x Tighter Tolerances
Zintilon can machine parts with tolerances as tight as+/ - 0.0001 in -10x greater precision compared to other leading services.
World Class Quality
Zintilon provides aerospace parts for leading aerospace enterprises, verified to be compliant with ISO9001 quality standard by a certified registrar. Also, our network includes AS9100 certified manufacturing partners, as needed.
From Prototyping to Mass Production
Zintilon operates under ISO 9001 and provisions tailored engineered parts to coffee grinder makers, espresso machine manufacturers, burr assemblies distributors, and consumer appliances manufacturers around the globe.
Prototype Coffee Grinder Components
Prototype assemblies of coffee grinder parts with intricate detail which allows the user to grind coffee beans will help the user to test the grinding quality. It will help the user to evaluate the burr's alignment, and test the adjustment mechanism, and verify the distribution of the coffee grounds before going into the mass production stage.
Key Points:
Key Points:
- Rapid prototyping with grind quality validation
- Tight tolerances (±0.008mm for burr tooth geometry)
- Test grinding performance, adjustment range, and durability early
EVT – Engineering Validation Test
The design and layout of coffee grinder components means that it has attained the required dimensional accuracy, burr alignment, and grind consistency expectations which would give a go-ahead for the prototype manufacture. It would help in determining the size of the grind particles. It would also show if the mechanism of adjustment would hinder the grinding action to provide a clear mechanism to work with.
Key Points:
Key Points:
- Validate prototype functionality with particle size analysis
- Rapid design iterations for burr geometry optimization
- Ensure readiness for production with FDA compliance validation
DVT – Design Validation Test
Evaluate different materials and heat treatment methods of the coffee grinder parts to measure wear resistance and grinding consistency. This is to evaluate the consumer appliance system to ensure the expected extraction quality and certification standards are met prior to production.
Key Points:
Key Points:
- Confirm design integrity and grind uniformity specifications
- Test multiple steels and hardening processes
- Ensure production-ready performance with retention testing
PVT – Production Validation Test
Evaluate the production of coffee grinder parts. Assess challenges of production consistency to evaluate the controlled burr alignment and surface finish of the manufacturing process.
Key Points:
Key Points:
- Test large-scale production capability with grind distribution validation
- Detect and fix process issues early in heat treatment
- Ensure consistent part quality and grinding performance
Mass Production
Manufacture coffee grinder components to ensure appliance performance and meet the ever-increasing demand from coffee grinder manufacturers and suppliers for espresso equipment.
Key Points:
Key Points:
- Consistent, high-volume production with grind quality guarantee
- Precision machining for consumer goods quality
- Fast turnaround with strict quality control and FDA compliance
Simplified Sourcing for
the Consumer Goods Industry
Our aviation industry parts manufacturing capabilities have been verified by many listed companies. We provide a variety of manufacturing processes and surface treatments for aerospace parts including titanium alloys and aluminum alloys.
Explore Other Consumer Goods Components
Browse our complete selection of CNC machined consumer goods components, engineered for precision and production efficiency. From custom metal housings and plastic molds to intricate handles, connectors, and decorative fittings, we deliver tailored solutions to meet diverse consumer product manufacturing needs.
Consumer Goods Industry, Coffee Grinder Components, Machining Capabilities
With our expertise, CNC multi-axis machining centers, 5-axis simultaneous milling machines, and precision Swiss turning machines are able to deliver high quality and precision made coffee grinder components. Knowing the consumer goods industry, the company transfers to every part the attention to detail that creates coffee grinder components. Every part, such as conical hardened steel burrs, grinding steel burrs, micro-stepped grind adjustment rings, static dissipative bean hopper bodies, polished flat burrs, and anti-vibration motor shafts, is designed and highly reliable for food practices and for processing over 500 kg of coffee beans.
We do precise CNC milling for burr tooth patterns keeping dimensional accuracy of ±0.008 mm and cutting angle tolerance of ±0.3 degrees and for complex conical burr geometries involving 5-axis machining with profile tolerance of ±0.010 mm. We also do precise turning for burr mounting surfaces with diameter tolerances of ±0.010 mm and Eccentricity of 0.008 mm, and precision flat face burr grinding with flatness achievable to ±0.005 mm and surface finishing of Ra 0.4μm, thread adjustment mechanism milling with pitch accuracy of ±0.012 mm and backlash control of 0.05mm, as well as precision boring of bearing seats with tolerances of ±0.008 mm. Finally, we do bulk material particle size distribution and wear testing for 100 kg grinding capacity.
We manufacture food-grade compliant burr sets from hardened stainless steel 420 with a hardness rating of HRC 58-62 and grinding chambers from stainless steel 304 with FDA CFR 21 certification and corrosion resistance. Our premium burrs are made from hardened tool steel (D2) giving them extreme wear resistance and edge retention. We also manufacture 6061-T6 Aluminum motor housings with anodized protection and heat dissipation. Other materials we use are food-grade ABS plastic for bean hoppers with static dissipative additives and food-grade polycarbonate (PC) for transparent UV resistant hopper windows. We also use brass for adjustment mechanism threads with consistent friction characteristics and ceramic coatings on burrs to extend wear life without altering the flavor of the coffee. We pride ourselves in food safety compliance to FDA CFR 21 and EU Regulation 10/2011, grind consistency down to a particle size deviation of 10%, and the ability to operate mechanically for more than 500 kg of coffee processing in a 5-year continuous daily use.
We do precise CNC milling for burr tooth patterns keeping dimensional accuracy of ±0.008 mm and cutting angle tolerance of ±0.3 degrees and for complex conical burr geometries involving 5-axis machining with profile tolerance of ±0.010 mm. We also do precise turning for burr mounting surfaces with diameter tolerances of ±0.010 mm and Eccentricity of 0.008 mm, and precision flat face burr grinding with flatness achievable to ±0.005 mm and surface finishing of Ra 0.4μm, thread adjustment mechanism milling with pitch accuracy of ±0.012 mm and backlash control of 0.05mm, as well as precision boring of bearing seats with tolerances of ±0.008 mm. Finally, we do bulk material particle size distribution and wear testing for 100 kg grinding capacity.
We manufacture food-grade compliant burr sets from hardened stainless steel 420 with a hardness rating of HRC 58-62 and grinding chambers from stainless steel 304 with FDA CFR 21 certification and corrosion resistance. Our premium burrs are made from hardened tool steel (D2) giving them extreme wear resistance and edge retention. We also manufacture 6061-T6 Aluminum motor housings with anodized protection and heat dissipation. Other materials we use are food-grade ABS plastic for bean hoppers with static dissipative additives and food-grade polycarbonate (PC) for transparent UV resistant hopper windows. We also use brass for adjustment mechanism threads with consistent friction characteristics and ceramic coatings on burrs to extend wear life without altering the flavor of the coffee. We pride ourselves in food safety compliance to FDA CFR 21 and EU Regulation 10/2011, grind consistency down to a particle size deviation of 10%, and the ability to operate mechanically for more than 500 kg of coffee processing in a 5-year continuous daily use.
Aerospace
Materials & Finishes
Materials
We provide a wide range of materials, including metals, plastics, and composites.
Finishes
We offer superior surface finishes that enhance part durability and aesthetics for applications requiring smooth or textured surfaces.
Specialist Industries
you are welcome to emphasize it in the drawings or communicate with the sales.
Materials for Coffee Grinder Components
Calculating the volume and weight of coffee grinder components, our CNC machining shop has over a dozen food-safe materials, hardened stainless steels, and wear-resistant alloys to facilitate rapid prototype development for precision consumer goods, as well as maintaining FDA, EU, and coffee equipment performance specifications.
Stainless steel alloys have high strength, ductility, wear and corrosion resistance. They can be easily welded, machined and polished. The hardness and the cost of stainless steel is higher than that of aluminum alloy.
Price
$ $ $
Lead Time
< 7 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
High machinability and ductility. Aluminum alloys have good strength-to-weight ratio, high thermal and electrical conductivity, low density and natural corrosion resistance.
Price
$ $ $
Lead Time
< 7 days
Tolerances
Down to ±0.003 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Titanium is an advanced material with excellent corrosion resistance, biocompatibility, and strength-to-weight characteristics. This unique range of properties makes it an ideal choice for many of the engineering challenges faced by the medical, energy, chemical processing, and aerospace industries.
Price
$$$
Lead Time
< 10 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Brass is mechanically stronger and lower-friction metal properties make CNC machining brass ideal for mechanical applications that also require corrosion resistance such as those encountered in the marine industry.
Price
$$$
Lead Time
< 10 days
Tolerances
Down to ±0.005mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Highly resistant to seawater corrosion. The material’s mechanical properties are inferior to many other machinable metals, making it best for low-stress components produced by CNC machining.
Price
$ $ $ $ $
Lead Time
< 10 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Few metals have the electric conductivity that copper has when it comes to CNC milling materials. The material’s high corrosion resistance aids in preventing rust, and its thermal conductivity features facilitate CNC machining shaping.
Price
$$$
Lead Time
< 10 days
Tolerances
Down to ±0.005 mm
Max part size
3000*2200*1100 mm
Min part size
2*2*2 mm
Let’s Build Something Great, Together
FAQs: Precision Coffee Grinder Components for Consumer Goods Industry Applications
Components of precision coffee grinders are hardened stainless steel conical burrs (outer diameters 38-71mm) with tooth geometry tolerances of ±0.008mm and hardness HRC 58-62, flat burr assemblies (diameters 58-83mm) with flatness of ±0.005mm and surface finishes Ra 0.4μm, grind adjustment rings with micro-step (18-40 settings) and thread pitches of ±0.012mm, bean hoppers (200-500g, wall thickness 2-4mm), motor coupling shafts with diameters tolerances of ±0.010mm and concentricity of 0.008mm, and grinding chamber housings with mounting hole errors of ±0.020mm. All components will be FDA CFR 21 compliant for food contact.
Hardened stainless steel 420 provides food safety and permits HRC 58-62 hardness for longer burr life. Its excellent corrosion resistance prevents rusting in humid conditions, zero flavor transfer keeps coffee taste pure, and wear resistance aids in processing 500+ kg beans. Also, stainless steel 304 provides FDA CFR 21 compliance in coffee grinding chambers, and other superior corrosion resistance from coffee oils and rancid cleaning solution, ease of cleaning and aesthetically good appearance in consumer appliances. Furthermore, Tool steel D2 has excellent wear resistance (HRC 60-62 hardness) superior edge retention to sustain consistent grinding for 1,000+ kg capacity and to grind into precise tooth geometry ±0.008mm of such gradeability.
The CNC milling machines create the burr pattern with a tolerance of ±0.008mm within the burr cutter profile and a cutting angle tolerance of ±0.3 degrees. The 5-axis machines are able to create cone burr profiles with a tolerance of ±0.010mm in the profile. The lathes use precision turning to create the mounting surfaces with a tolerance of ±0.010mm in the diameter and 0.008mm concentricity. The grinding machines are able to achieve burr faces with a tolerance of ±0.005mm in flatness and a Ra surface finish of 0.4μm. The adjustment mechanism was created with a thread milling with a pitch tolerance of ±0.012mm and a backlash of <0.05mm. The surfaces of the parts go through several treatments like vacuum heat treatment (HRC 58-62), electropolishing (Ra 0.3-0.5μm), passivation per ASTM A967 and in the case of stacks or woven burrs we also finish with a ceramic coating to improve the application.
We maintain burr tooth geometry tolerance ±0.008mm ensuring consistent particle size distribution ±10% standard deviation, cutting angle accuracy ±0.3 degrees for optimal grinding efficiency, flat burr flatness ±0.005mm preventing uneven wear and channeling, mounting surface concentricity 0.008mm ensuring wobble-free rotation at 400-1,400 RPM, adjustment thread pitch accuracy ±0.012mm with backlash <0.05mm for precise grind setting control, bearing seat tolerance ±0.008mm, surface finish Ra 0.4-0.8μm optimizing particle flow, and burr hardness HRC 58-62 providing wear resistance for 500+ kg grinding capacity.
Yes, we provide rapid prototyping with CMM inspection (±0.005mm accuracy), burr tooth geometry verification using optical microscopy, flatness measurement with precision dial indicators (0.001mm resolution), particle size distribution analysis using laser diffraction (measuring 100-1,000 microns), hardness testing per Rockwell HRC scale, concentricity measurement using precision runout gauges, grind consistency testing with 10+ kg coffee samples, and food safety certification per FDA CFR 21. We support low-volume production (1,000-15,000 annually) for specialty grinders and high-volume manufacturing (tens of thousands to millions) with dimensional certification, material compliance per FDA and EU 10/2011, particle distribution reports, wear testing data, and ISO 9001 quality documentation.
