Commercially Pure Titanium Alloys (TA Series: TA1, TA2, TA3, TA4)
Here’s a detailed comparison of the properties of TA1, TA2, TA3, and TA4 (commercially pure titanium alloys) :
Classification & Composition
- Common Features: All are α-phase (single-phase) titanium, primarily composed of Ti with trace interstitial elements (O, N, C, Fe). Impurity levels increase from TA1 to TA4.
- Key Differences: Oxygen content directly impacts strength and ductility (per GB/T 3620.1):
- TA1: Highest purity, lowest impurities.
- TA4: Highest impurity content, highest strength but reduced ductility.
Mechanical Properties
| Grade | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (HV) |
|---|---|---|---|---|
| TA1 | 240–370 | 170–300 | ≥30 | 120–150 |
| TA2 | 400–550 | 280–450 | ≥25 | 150–180 |
| TA3 | 500–650 | 380–550 | ≥20 | 180–210 |
| TA4 | 550–750 | 480–620 | ≥15 | 200–240 |
Trends: Strength improves with impurity content (TA1 lowest, TA4 highest), while ductility decreases.
- Strength: TA1 < TA2 < TA3 < TA4 (oxygen solid-solution strengthening).
- Ductility: TA1 > TA2 > TA3 > TA4 (higher impurities reduce elongation).
Physical & Chemical Properties
- Density: ~4.51 g/cm³ (similar for all grades).
- Corrosion Resistance:
- Excellent in oxidizing media (e.g., seawater, nitric acid, chlorides), surpassing stainless steel.
- Ranking: TA1 ≈ TA2 ≈ TA3 ≈ TA4 (minimal impact from impurities).
- Heat Resistance: Max service temperature ≤350°C (oxidizes at higher temperatures; β-phase alloys tolerate more heat).
Formability & Weldability
- Cold Working:
- TA1/TA2: Superior ductility, suitable for cold rolling, stamping, bending. TA1/TA2 offer superior ductility for cold working.
- TA3/TA4: Require annealing (e.g., 800°C) to restore ductility. TA3/TA4 require hot working due to higher strength.
- Hot Working: All grades need hot forging/rolling at 700–900°C (α-phase zone).
- Welding:
- All grades are weldable (TIG, laser) without post-weld heat treatment.
- TA1/TA2 welds exhibit better toughness; TA3/TA4 may show slight embrittlement.
Typical Applications
| Grade | Applications |
|---|---|
| TA1 | Chemical lining, biomedical implants (dental, stents), seawater desalination heat exchangers. |
| TA2 | Marine components, electrolytic copper foil cathodes, pharmaceutical reactors (high ductility + corrosion resistance). |
| TA3 | Medium-strength structures (submarine valves, pump housings), acid-resistant piping. |
| TA4 | High-stress corrosion-resistant parts (aerospace fasteners), petrochemical pressure vessels (trades ductility for strength). |
Material Selection Guide
- Choose TA1/TA2: For high ductility, cold forming, or biocompatibility (e.g., medical implants).
- Choose TA3/TA4: For higher strength in corrosive, load-bearing environments (e.g., chemical processing).
TC4(Ti-6Al-4V, α+β Alloy)
Here’s a detailed technical profile of TC4 (Ti-6Al-4V) titanium alloy:
TC4 (Ti-6Al-4V) Titanium Alloy Characteristics
Fundamental Properties
- Designation:
- ASTM Grade 5 / UNS R56400
- China GB: TC4
- Type: α+β dual-phase alloy
- Composition (wt.%): Contains 6% aluminum (Al) and 4% vanadium (V), featuring α+β dual-phase structure at room temperature.
- Ti: Balance (≈90%)
- Al: 5.5-6.75% (α stabilizer)
- V: 3.5-4.5% (β stabilizer)
- Fe ≤0.30%, O ≤0.20%, C ≤0.08%, N ≤0.05%
Mechanical Properties
| Property | Typical Value | After Heat Treatment* |
|---|---|---|
| Tensile Strength (MPa) | 895-930 | 1000-1100 |
| Yield Strength (MPa) | 825-869 | 950-1050 |
| Elongation (%) | 10-15 | 8-12 |
| Reduction of Area (%) | 25-30 | 20-25 |
| Hardness (HV) | 310-360 | 340-400 |
| Fatigue Limit (MPa) | 500-600 (10⁷ cycles) | 550-650 (10⁷ cycles) |
| Fracture Toughness (MPa√m) | 55-75 | 50-70 |
*Solution treatment (955°C) + aging (538°C)
Physical Properties
- Density: 4.43 g/cm³
- Melting Range: 1604-1660°C
- Thermal Conductivity: 6.7 W/(m·K) at 20°C
- Specific Heat: 526 J/(kg·K) at 20°C
- Heat Resistance: Suitable for long-term service up to 400°C (vs. ≤350°C for pure titanium).
- Electrical Resistivity: 1.78 μΩ·m
- Elastic Modulus: 110-114 GPa
Performance Advantages
- Strength-to-Weight Ratio: 25% higher than steel at equivalent strength. Tensile strength ~900-1100 MPa, significantly higher than pure titanium but with reduced ductility (elongation ≥10%).
- Corrosion Resistance:
- Excellent in seawater, chlorides, organic acids
- Forms stable TiO₂ passive film
- Superior to stainless steels in reducing acids
- Biocompatibility: ASTM F136 compliant for medical implants
- Cryogenic Performance: Retains ductility down to -253°C
Processing Characteristics
- Hot Working: Optimal at 900-955°C (β transus ~995°C)
- Cold Working: Limited to <10% deformation (annealing required)
- Processability: Excellent hot workability but challenging for cold working; requires protective gas welding (e.g., TIG).
- Machining:
- Low thermal conductivity causes heat buildup
- Requires sharp tools, low speeds, high feed rates
- Welding:
- Recommended methods: EBW, LBW, GTAW (Ar shielding)
- Post-weld stress relief at 650°C recommended
- Heat Treatment: Can be strengthened via solution treatment and aging.
Standard Specifications
- Aerospace: AMS 4911, AMS 4928
- Medical: ASTM F1472, ISO 5832-3
- Industrial: ASTM B348, MIL-T-9047
Typical Applications
- Aerospace: Landing gear, turbine blades, airframe components
- Biomedical: Orthopedic implants, surgical instruments
- Industrial: Pressure vessels, marine hardware
- Automotive: High-performance connecting rods
Limitations
- Moderate wear resistance (requires surface treatments)
- Susceptible to hydrogen embrittlement >80°C in acidic environments
- Higher cost than steel/aluminum alternatives
This alloy represents the most widely used titanium material globally, accounting for ~50% of all titanium applications. Its properties can be further optimized through:
- Thermomechanical processing (e.g., β annealing)
- Surface engineering (e.g., anodization, nitriding)
- Additive manufacturing (process-specific heat treatments)
Key Comparison
TC4 is an α+β dual-phase alloy with much higher strength (≥900 MPa) but lower ductility and slightly reduced corrosion resistance. It’s costlier and used in aerospace/advanced engineering.
| Property | TA1-TA4 (Pure Ti) | TC4 (Ti-6Al-4V) |
|---|---|---|
| Microstructure | α-phase | α+β dual-phase |
| Strength | Low-Medium (240-550 MPa) | High (900-1100 MPa) |
| Ductility | Excellent (TA1 best) | Moderate |
| Corrosion Res. | Outstanding | Good (slightly inferior) |
| Temp. Limit | ≤350°C | ≤400°C |
| Typical Uses | Chemical/Biomedical | Aerospace/Heavy-load |
Material Selection Guide
- For high ductility & corrosion resistance: Prioritize TA1/TA2
- For higher strength: Consider TA3/TA4 or TC4
- For high-temperature/structural applications: TC4 (cost-performance trade-off required)
